1. Excellent Striping performance of tight buffer fiber.
2. Cable diameter and bending radius small, It can installation freely in narrow room .
Geometrical Characteristics
Cable Type | 2 | 4 | 6 | 8 | 12 | 16 | 24 |
Cable Dimension (mm) | 5.0±0.2 | 5.1±0.2 | 5.3±0.2 | 5.9±0.2 | 6.6±0.2 | 7.5±0.2 | 8.5±0.2 |
Cable Weight (kg/km) | 19 | 21 | 23 | 28 | 34 | 46 | 57 |
TBF Diameter(μm) | 900±50 | ||||||
Transmission Characteristics
Item | SMF | 50/125 | 62.5/125 |
1310/1550(nm) | 850/1300(nm) | 850/1300(nm) | |
Attenuation (dB/km) | ≤0.40/0.30 | ≤3.5/1.5 | ≤3.5/1.5 |
Minimum Bandwidth (Mhz·km) | ................... | ≥400/400 | ≥160/500 |
Fiber
Fiber Type (core/cladding dimension) | 8.3/125. 50/125. 62.5/125 |
Environmental Characteristics
Operating Storage Temperature | －20℃～＋60℃ |
Simplex cable,2-12 simplex cable are stranded around the metallic central strength member, arrange circuit according to clockwise order in turn, then used wrap winding, the APL is longitudinal covering, the cable is completed with outer sheath.
1.900μm Hytrel, PVDF, aramid yarn, soft flame-retardant jacket.
Element: Simplex cable are stranded around the non-metallic central strength member
1. 900μm loose tube,and 12 flat tube.
