A. Round
Cable Type | Φ0.9 |
Cable Diameter (mm) | 0.9 |
Cable Weight (kg/km) | 0.6 |
B. Flat
Cable Type | Φ12-fibers |
Cable Diameter (mm) | 2.5× 4.5 |
Cable Weight (kg/km） | 4.4 |
Environmental Characteristics
Operating Storage Temperature | -20℃~+60℃ |
Simplex cable,2-12 simplex cable are stranded around the metallic central strength member, arrange circuit according to clockwise order in turn, then used wrap winding, the APL is longitudinal covering, the cable is completed with outer sheath.
1. Fiber ribbon,aramid yarn,flame-retardant jacket
2. Suited to SM fiber
Element: Simplex cable are stranded around the non-metallic central strength member
1.900μm loose tube,and 12 flat tube.
