1.Special low-bend sensitivity fiber provides high bandwidth and excellent communication transmission property
2.Suitable for the connection of indoor between outdoor.
Geometrical Characteristics
Fiber Core | 1、2 |
Cable Dimension(mm) | 7.0 |
Cable Weight (kg/m) | 35 |
Mechanical Characteristics
| Tensile Strength(N) | Long Term | 30 |
| Short Term | 60 | |
| Bending Radius(cm) | Dynamic | 20xD(D:Cable Diameter) |
| Static | 10xD(D:Cable Diameter) |
Transmission Characteristics
| SMF | |
| 1310/1550(nm) | |
| Attienuation (dB/km) | ≤0.40/0.30 |
| Minimum Bandwidth(Mhz·km) | ----------------- |
Fiber
| Fiber Type (core/cladding dimension) | G.657A |
Environmental characteristics
| Operating Storage temperature | -40℃~+70℃ |
1.Suited to SM fiber and MM fiber (50 μm and 625μm).
2.It is ideal choice of fiber optic temperature transmission project.
3.Supply gel-filled or gel-free loose tube
1.Special low-bend sensitivity fiber provides high bandwidth and excellent communication transmission property.
2.Two parallel strength members ensure good performance of crush resistance to protect the fiber.
3.Simple structure,light weight and high practicability.
4.Novel flute design, easily strip and splice, simplify the installation and maintenance.
5.Single steel wire as the additional strength member ensures good performance of tensile strength.
1.Sheath mechanical and physics performance content correlative standard request.
2.Diameter and bending radius small, lt can installation freely in narrow room.have both optical signal transmission and electricity transmission.
1.600 um tight buffer fiber, steel tube protect, reinforcing steel-wire braiding flame-retardant jacket . High indentation strength.High tensile strength gopher protected, small diameter, flexibility and easy bend.
2.Excellent stripping performance of tight buffer fiber.
3.Suited to SM fiber and MM fiber (50μmand 62.5umm).
4.It is ideal choice of fiber optic temperature transmission project.
